PD30W POWER ELF CE EMC Certificate
Download
| IN Mode | |
| Input | Mobile phone chargers |
| Power bank | |
| Portable power station, and other power supply devices | |
| Output | DC 14.5V/2A(Require≥30W Charger or power supply devices) |
| DC 14.5V/1.2A(Require≥18W Charger or power supply devices) | |
| DC 14.5V/0.6A(Require≥10W Charger or power supply devices) | |
| Voltage limit | 14.6V |
| Temperature range | Working:-10°C-45°C, -50° F-113° F |
| Storage:-20°C-60°C, -68° F-140℉ | |
| Charging mode | Fully automatic |
| Suitable for batteries | 12V Lead Acid battery |
| 12.8V LiFePo4 lithium battery | |
| OUT Mode | |
| Input | 12V Lead acid battery |
| 12.8V LiFeP04 lithium battery | |
| Output | 5A 3A, 9V 3A, 12V 2.5A, 15V 2A, 20V 1.5A, MAX 30W |
| Supported protocols | PD 2.0/3.0, QC 2.0/3.0, AFC, FCP, SCP, PPS, Apple BC 1.2, Samsung |
| Certificate | CE, FCC, ROHS |
| Width |
| 882mm |
| 34.7in |
Low-voltage 5V input ensures safe and stable charging, even from power banks.
Built-in over-voltage, over-current, and short-circuit protection for worry-free use.
Advanced temperature control technology prevents overheating and ensures stable performance.
Engineered to perform in rainy rides and rugged outdoor conditions.
Waterproof charging interface for safe, durable operation in all weather.
Automatically switches to maintenance mode when fully charged to prevent overcharging.
Intelligent battery type detection adjusts the charging strategy to help extend battery life.
12V Battery Charging: Supports 12.8V LiFePO₄ batteries with up to 2A charging current, quickly solving low battery issues.
Device Fast Charging: Delivers 30W PD/QC/AFC fast charging via Type-C for phones, tablets, and more — perfect for top-ups during long rides.
Pocket-sized design makes it easy to carry and use on the go.
Connects directly to motorcycle batteries or power banks for on-demand power.
Supports engine starting in emergency situations (with PD 30W fast charge mode).
Compatible with 12V batteries in motorcycles, e-bikes, boats, ATVs, and more.
Provides reliable power for phones, GPS devices, action cameras, and other outdoor gear — no more battery anxiety during long adventures.
